Description:

The Diamondback is a commercially built and consumer priced workhorse. The 23 horsepower Kawasaki FR691V engine and Hydro-Gear ZT-3200 transmission guarantees a fast, smooth ride every time. With a three-year limited warranty, you will come to love the reliability, exceptional value and world-proven performance that Worldlawn provides.

Features:

• 3200 Hydro-Gear transmissions
• R.O.P.S. standard
• Triple layer spindle support
• Discharge, mulch, or collect
• FR Kawasaki Series
• Worldlawn 803 V-Twin

Specification:

• Model Number: WYDB60FR730V32
• Length: 77.4 inches
• Width: 73 inches
• Width w/ Deflector Up: 61 inches
• Wheelbase: 50.5 inches
• Wheel Track Width: 49.5 inches
• Weight: 1020 lbs
• Front Tires: 13 – 6.50 x 6 Smooth
• Rear Tires: 23 – 10.50 x 12 Turf
• Deck Material: 8 Gauge Steel
• Cut Width: 60 inches
• Cutting Heights: 1.5" – 4.75"
• PTO: Electric
• Fuel Capacity: 9.5 gallons
• Engine Brand: Kawasaki (KAW)
• Engine HP: 24 HP
• Forward Speed: 9 mph
• Powered Reverse: Yes
• Blades: 3 – 20 inches
• Transmission: Hydro-Gear ZT-3200
